49
Setting up using batteries:
Important: To avoid operating problems, please take note of battery
polarity if inserting any batteries
1) Pull away the rain cover of the thermo-hygro sensor to reveal the
three sockets (for the wind sensor, rain sensor and the base sta-
tion)
2) Connect the attached cables of wind and rain sensors to the corre-
sponding sockets of the thermo-hygro sensor by clicking them into
place
3) Open the battery cover of the thermo-hygro sensor located below
the three sockets and insert 2 x AA, IEC LR6, 1.5V batteries and
close the cover
4) Open the base station’s battery cover located at the back of the unit
and insert 3 x AA, IEC LR6, 1.5V batteries into the battery com-
partment and close the battery cover
Compartment
