2.1.2 Floor-Mounting the A31
Floor-Mounting Procedure
Floor-mounting the 70, 72, 44, and 47B enclosures is standard. To floor-mount the A31, install four anchor
bolts into the floor. Place the inverter on the anchor bolts, add appropriate mounting hardware, and tighten
securely. Refer to the figure below for hardware specifications and floor-mounting dimensions. All dimensions are
given in inches.
Case Size
A
B
Bolt Size
70
25.75"
13"
1/4"
72
25.75"
17.5"
1/4"
44
22"
17.06"
3/8"
47B
36.5"
37.5"
9/16"
Figure 4 – A31 Enclosure Footprint
