Page 18
Key Model ORDER
No. Description No. PART NO.
FUEL SYSTEMS
1 Oil Burner Assembly 2000 L0060000
1 Oil Burner Assembly 3000 L0060100
2 Oil Filter (Not Shown) All P0065100
3 Oil Filter Cartridge (Not Shown) All P0065500
4 3/8” Oil Line, Pump to Filter All 10430402
ELECTRICAL SYSTEM
5 Thermostat All R0318800
6 Thermostat Knob All R0010700
7 Thermostat Dial All H0048400
8 Thermostat Cover All 10388300
9 Thermostat Back All 10368000
10 Thermostat Base Plate All 10362000
11 Pressure Switch, 1-10 PSI All R0045400
12 Siphon Loop Cover All 10403400
13 Siphon Loop Assembly All R0057800
14 High-Limit Switch Assembly All R0023200
15 High-Limit Switch, 135°F All R0022700
16 High-Limit Switch, 150°F All R0012700
17 High-Limit Switch Harness (115V) All R0057500
18 High-Limit Switch Harness All R0057700
19 High-Limit Switch Cover All 10401100
20 Switch Cover All E0078300
21 ON/OFF Switch All E0078200
22 Oil Burner Harness All R0057600
23 Connector Elbow 90° All P0059800
WATER SYSTEMS
24 Heat Exchanger Assembly, Complete 2000 10927101
24 Heat Exchanger Assembly, Complete 3000 10927102
25 Heat Exchanger 2000 10927001
25 Heat Exchanger 3000 10927002
26 Inlet/Outlet Header All 10403700
27 End Cap (1/2” tap) All 10403900
28 End Cap (No tap) All 10406100
29 End Cap (1/4” tap) All 10403800
30 Tee Baffle (5) 2000 10926901
30 Tee Baffle (5) 3000 10926902
31 End Baffle (2) 2000 10387702
31 End Baffle (2) 3000 10387703
32 Tube Gaskets (12) All S0063400
34 Grommet (2 Required) All S0098800
35 Brass Plug, 3/4” (1) All P0027000
36 Drain Valve Extension All P0059900
37 Drain Plug, 1/4” (3) All P0026800
38 By-Pass Assembly All R0020600
39 By-Pass Valve Rod All S0074300
40 By-Pass Valve Disc All S0074200
41 By-Pass Valve Rod Retainer All S0008700
42 By-Pass Valve Spring 2000 S0061300
42 By-Pass Valve Spring 3000 S0061300
43 Flange & Gasket Assembly All R0031900
44 Flange, 1 1/2" All 10309200
45 Flange Gasket, 1 1/2" All S0053100
46 Flange Sleeve, 1 1/2" All S0028000
47 Flange Bolt All F0031700
48 Gasket All S0065300
Key Model ORDER
No. Description No. PART NO.
FIRE BOX & JACKET COMPONENTS
49 Burner Tube Gasket All N0006600
50 Burner Support Bracket All 10392000
51 Burner Compartment Door 2000 10412203
51 Burner Compartment Door 3000 10412204
52 Fire Box Plug All T0020700
53 Fire Box Cover Plate All 10425800
54 Gap Spacer (Return) All 10401000
55 Flue Collector Assemby All 10406301
55 Flue Collector Assemby All 10406302
56 Flue Top Assembly 2000 10405001
56 Flue Top Assembly 3000 10405002
57 Inner Stack All 10390000
58 Flue Collector Shield 2000 10404501
58 Flue Collector Shield 3000 10405002
59 Vent Blade (10) All 10319300
60 Gap Spacer (In/Out) All 10400900
61 Hold Down Clip All 10401200
62 Fire Box 2000 T0020500
62 Fire Box 3000 T0020600
63 Fire Box Cover (2) 2000 10400801
63 Fire Box Cover (2) 3000 10400802
OIL BURNER PARTS & COMPONENTS (Not Shown)
Air Tube Screw All F0004300
Pilot Bracket Screw All F0031300
End Air Shutter All N0000200
Bulk Air Band All N0000300
Air Tube Gasket All N0000800
Motor, 1/7 H.P. , 3450 RPM All N0001000
Blower Wheel 4- 1/4” x 3- 7/16” All N0001400
Flexible Coupling All N0001500
Fuel Unit, Two Stage All R0140100
Pump Outlet Fitting All N0002000
Connector Tube Assembly All N0002200
Ignition Transformer All R0140200
Contact Spring Terminals All N0002600
Air Tube Combination All N0002900
Nozzle Line Electrode Assembly All N0003100
Electrode Clamp All N0003500
Electrode Rod & Tip All N0004000
Burner Head & Screws All N0004500
Burner Head 2000 N0004700
Burner Head 3000 N0007700
Delavan Nozzle, 2.25 3000 N0007500
Delavan Nozzle, 1.65 2000 N0007600
Primary Control All R0140300
Honeywell Cad Cell All N0006100
By-Pass Plug All N0007000
By-Pass Plug All N0007100
1/8” Burner Head Plug All P0026100
1/4” Burner Head Plug All P0026800
OPTIONAL EQUIPMENT
64 Pressure Relief Valve, 3/4" NPT, 75 PSI All R0040400
Chimney Cap - 9" (Not Shown) All D0014900
For more information:
Telephone: Main: (415)382-8220 Order Fax: (800)526-3928
Customer Service: Ext. 245 Warranty/Service: Ext. 260 Literature Requests: Ext. 237
Pool Systems Address: 21 Pimentel Ct., Novato, CA 94949 Mailing Address: P.O. Box 6101, Novato, CA 94948-6101
Web Address: http://www.jandy.com/
International: 480 S. Service Rd. West, Oakville, Ontario, Canada L6K 2H4 (905)844-8233 voice (905)844-2635 fax
SECTION 6.
Parts List for Model DP
Oil-Fired Heater
