9. Appendix
PLM+ SERIES Operation Manual rev 3.0.1
73
9.4. Current Draw and Thermal Dissipation Specifications
different operating conditions for each PLM+ Series device.
1. Standby Mode
2. Power On (Idle - No Signal)
3. Power On (Normal Operation - Pink Noise 1/8 of Rated Power)
4. Power On (Heavy Duty Operation - Pink Noise Max Power)
5. Power On (Pilot Tone Operation - 20 kHz Sine Wave)
Table 9.2: PLM5K44 Current Draw and Dissipation Specifications
PLM 5K44
Level Load
Rated power per
channel
Line Current Measured Power (W) Thermal Dissipation
( A ) In Out Dissipated BTU/hr kCal/hr
Mains Voltage 100 VAC
Standby
0.2 7 0 7 24 6
Power on, Idling,Green Mode
0.6 59 0 59 201 51
Power on,Idling, Performance Mode
0.8 78 0 78 267 67
Pink Pseudo Noise
16 Ω/ Ch. 700 x 4 5.1 501 350 151 515 130
8 Ω/ Ch. 1250 x 4 8.9 881 625 256 872 220
4 Ω/ Ch. 1250 x 4 9.3 915 625 290 990 249
2 Ω/ Ch. 900 x 4 7.8 771 450 321 1097 276
100V/ Ch. 1250 x 4 8.9 880 625 255 870 219
70V/ Ch. 1250 x 4 10.0 982 650 332 1133 285
Mains Voltage 120 VAC
Stand
by
0.3 7 0 7 24 6
Power on, Idling,Green Mode
0.5 59 0 59 200 50
Power on,Idling, Performance Mode
0.7 77 0 77 263 66
Pink Pseudo Noise
16 Ω/ Ch. 700 x 4 4.2 498 350 148 506 127
8 Ω/ Ch. 1250 x 4 7.3 856 625 231 788 199
4 Ω/ Ch. 1250 x 4 7.7 909 625 284 969 244
2 Ω/ Ch. 900 x 4 6.4 751 450 301 1027 259
100V/ Ch. 1250 x 4 7.3 857 625 232 793 200
70V/ Ch. 1250 x 4 8.0 949 650 299 1019 257
Mains Voltage 208 VAC
Standby
0.3 7 0 7 25 6
Power on, Idling,Green Mode
0.5 58 0 58 198 50
Power on,Idling, Performance Mode
0.5 77 0 77 263 66
Pink Pseudo Noise
16 Ω/ Ch. 7
00 x 4 2.4 481 350 131 447 113
8 Ω/ Ch. 1250 x 4 4.1 831 625 206 703 177
4 Ω/ Ch. 1250 x 4 4.4 883 625 258 881 222
2 Ω/ Ch. 900 x 4 3.7 734 450 284 969 244
100V/ Ch. 1250 x 4 4.1 832 625 207 707 178
70V/ Ch. 1250 x 4 4.6 920 650 270 922 232
Mains Voltage 230 VAC
Standby
0.3 7 0 7 25 6
Power on, Idling,Green Mode
0.4 58 0 58 197 50
Power on,Idling, Performance Mode
0.5 77 0 77 263 66
Pink Pseudo Noise
16 Ω/ Ch. 700 x 4 2.2 474 350 124 435 109
8 Ω/ Ch. 1250 x 4 3.7 817 625 192 625 165
4 Ω/ Ch. 1250 x 4 3.9 869 625 244 833 210
2 Ω/ Ch. 900 x 4 3.3 724 450 274 936 236
100
V/ Ch. 1250 x 4 3.7 822 625 197 544 137
70V/ Ch. 1250 x 4 4.1 908 650 258 881 222
