Chapter 6: Maintaining Your Filtered PCR Enclosure
Figure 6-1
HEPA Filter Changing Diagram & Filter Leak Test Diagram
Prefilter
Filter
Clamp Bolt
HEPA Filter
Sealing Surface
HEPA Filter
Gasket Side
Down as Shown
Gasket
Front Panel
Speed Control
Adjustment
Screw
