69
Appendix A: Replacement Part
Item Qty. Part Number Description
17A 1 3918500 Wiring Harness Main, 115V
17B 1 3918600 Wiring Harness Main, 230V
18A 1 3811500 Guardian Airflow Monitor Printed Circuit Board
18B 2 1885405 Screw Mach #6-32 x .31 PH Phil. S.S.
19A 1 3926600 Label, Front Class I
19B 1 3926700 Label, Front HEPA
20A 1 3910700 Airflow Switch
20B 2 1891808 Screw, Thread Cutting #6-32 x .50 PH
21A 1 3906200 Cover Plate for HEPA 2'
21B 1 3906201 Cover Plate for HEPA 3'
21C 1 3906202 Cover Plate for HEPA 4'
21D Multiple 1905617 Nut, KEPS 10-24
22A 1 or 2 1307000 Switch, Rocker (2 position)
22B 1 1306300 Switch, Rocker (3 position) – UV Light Only
23A 1 or 2 3904800 Front Panel, 2'
23B 1 3904801 Front Panel, 3'
23C 1 3904802 Front Panel, 4'
23D 1 4472400 Screw, Thread cut 10-24 x .50 Type F PH Phillips
24A 1 3916500 Impeller, Motorized 2' or 3' Enclosure, 115V
24B 1 3916501 Impeller, Motorized 2' or 3' Enclosure, 230V
24C 1 3903300 Impeller, Motorized 4', 115V
24D 1 3903301 Impeller, Motorized 4', 230V
24E 4 1601800 Vibration Isolator Mount
25A 1 1306900 Capacitor, 2', 115V 10 MFD
25B 1 1306900 Capacitor, 3', 115V 10 MFD
25C 1 1306600 Capacitor, 4', 115V 15 MFD
25D 2 1306800 Capacitor, 2', 230V 4 MFD (effective 2MFD)
25E 2 1306800 Capacitor, 3', 230V 4 MFD (effective 2MFD)
25F 1 1306800 Capacitor, 4', 230V 4 MFD
26A 1 1235400 Ballast, Fluorescent 2', 115V
26B 1 1235500 Ballast, Fluorescent 2', 230V
26C 1 1294000 Ballast, Fluorescent 3' or 4', 115V or 230V
27A 1 1235400 Ballast, UV 2' or 3', 115V
27B 1 1235500 Ballast, UV 2' or 3', 230V
27C 1 1233400 Ballast, UV 4', 115V
27D 1 1233600 Ballast, UV 4', 230V
28A 1 1325500 Speed Control, 115V
28B 1 1325501 Speed Control, 230V
29A 1 3910800 Upper Diffuser Screen 2'
29B 1 3910801 Upper Diffuser Screen 3'
29C 1 3910802 Upper Diffuser Screen 4'
30A 2 3916700 Clip, Upper Diffuser
