Chapter 6: Modifying Your Washer
Product Service 1-800-522-7658 45
The 16-place Pipet Insert, shown below accommodates 1 ml to 50 ml pipets. Two
of these inserts may be installed, if desired. Refer to the figure and follow the
instructions below to install a 16-place Pipet Insert.
To install a 16-place Pipet Insert:
1. Use the tool supplied with the Spindle Rack or a screwdriver to remove the six
spindles on either the front or rear of the spindle rack. Remove others if
necessary.
2. Replace the left and right spindles with the two short spindles that you
received with the Pipet Insert.
3. Replace all other spindles with the plastic plugs that you received with your
washer.
4. With the support facing the front of the spindle rack, slide the Pipet Insert
over the spindles until it completely seats.
5. Push pipets into the 16 receptacles and rest them on the support.
Note: Lower spindle racks are shipped with 34 long spindles and 2 shorter
spindles. If spindles are removed and then replaced, the shorter spindles should
be located on the front row in the second and third positions form the right side.
This will allow proper function of the detergent dispenser.
