Appendix C: Glassware Washer Specifications
Product Service 1-800-522-7658
68
FACTORY PROGRAM DESCRIPTIONS AND POSSIBLE USER SET POINTS
Rinse Only Plastic Glass Glass Plus Scientific Scientific Plus
Units Factory User set Factory User set Factory User set Factory User set Factory User set Factory User set
Delay Start (hr) 0 1-8 0 1-8 0 1-8 0 1-8 0 1-8 0 1-8
Wash 1 Time (min) 5 None 5 None 5 None 5 None 5 None
Detergent Disp (ml) 20 0-40 20 0-40 20 0-40 20 0-40 20 0-40
Steam N None N Y N Y Y N N Y N Y Y N
Wash 2 Time (min) 10 10,20,30,40 10 10,20,30,40 10 10,20,30,40 20 10,20,30,40 20 10,20,30,40
Wash 2 Temp ( F ) 122 100-140 140 100-199 140 100-199 158 100-199 158 100-199
(°C) 50 38-60 60 38-93 60 38-93 70 38-93 70 38-93
Wash 3 Time (min)
Wash 3 Temp ( F )
(°C)
Detergent Disp (ml) 20 0-40 20 0-40 20 0-40 20 0-40 20 0-40
Number of Rinses 1 0-6 2 0-6 3 0-6 3 0-6 4 0-6 4 0-6
No of Pure Rinses 0 0-6 0 0-6 0 0-6 0 0-6 0 0-6 0 0-6
Final Rinse ( F ) 100 100-140 122 100-140 140 100-199 140 100-199 158 100-199 158 100-199
(°C) 38 38-60 50 38-60 60 38-93 60 38-93 70 38-93 70 38-93
Rinse Aid Disp (ml) 0 0-6 0 0-6 0 0-6 0 0-6 0 0-6
Dry Time (min) 0 0 or 15-99 15 0 or 15-99 30 0 or 15-99 30 0 or 15-99 40 0 or 15-99 40 0 or 15-99
Dry Temp ( F ) 100 100-140 122 100-140 140 100-158 140 100-158 140 100-158 140 100-158
(°C) 38 38-60 50 38-60 60 38-70 60 38-70 60 38-70 60 38-70
Cool if > 50 None if > 50 None if > 50 None if > 50 None if > 50 None if > 50 None
Total Water
Consumption (gal)
3.4
3.4 - 20.4
13.6
6.8 - 27.2
17.0
6.8 - 27.2
17.0
6.8 - 27.2
20.4
6.8 - 27.2
20.4
6.8 - 27.2
(liters)
12.9
13-77
51.5
26-103
64.4
26-103
64.4
26-103
77.2
26-103
77.2
26-103
Total Wash Time
(Excluding delays
for heating water
and dry time) (min)
9 48 81 91 110 120
Note
Times shown are for tap water rinses. Pure rinses add 1.5 minutes per rinse.
Additional time is required to allow inlet water to heat up to the set temperature.
Steam adds 10 minutes to the total program time.
Program Times & Water Consumption
