48 | MSD Legend Series Operation & Maintenance Manual
Check Valve Assembly
Check Valve Assembly
Item Part Number Qty Description
1 513875 1 Check Valve Housing
2 511580 1 Plunger
4 511578 1 Spring
5 511579 1 Screw Plug
Torque to 103 ft. lbs. (140 Nm)
6 512515 2 O-Ring Seal
