H50/150 Smart – User Manual
14
3.2 ELECTRICAL REQUIREMENTS
The unit provides extra protection against the risk of electrical shock by grounding appropriate
metal parts. The extra protection may not function unless the power cord is connected to a
properly grounded socket. It is the user’s responsibility to assure a proper ground connection is
provided.
The following power options are available:
The unit is supplied with a European power cable. It is used to be connected with power supply.
Plug the cord into socket and plug the rear into electric socket of the unit. Then the unit is
ready to be used.
3.3 PLUMBING REQUIREMENTS
H50
The plumbing connections are located on the rear of the unit and labeled “SUPPLY” and
“RETURN”. Remove the plastic protective caps from both plumbing connections. Install the
barbed adapters to these connections.
Connect the fitting “SUPPLY” to the hose feeding the inlet of your application.
Connect the fitting “RETURN” to the hose from the outlet of your application. Clamp all
Unit
Voltage/V
Frequency
/Hz
Phases
Circuit
Capacity/A
Fuse
IP
Degree
Power
consumption
/W
Dissipated
heat load
BTU/h
H50-500/DF
230
50/60
1
2
4
20
460
1800
H50-500/115
115
60
1
4
10
20
460
1800
Smart
H150-1000N
230
50/60
1
6
8
20
1300
3500
115
60
1
10
10
20
1300
3500
Smart
H150-1500NS
230
50/60
1
10
16
20
1700
5200
115
60
1
20
20
20
1700
5200
Smart
H150-2100NS
230
50/60
1
10
16
20
2300
7200
115
60
1
20
25
20
2300
7200
Smart
H150-3000NS
230
50/60
1
13
16
20
2900
10300
H150-5000N
230
50
1
15
16
20
3450
17000
H150-7000N
400/440
50/60
3
9A/P
10
20
4100
23900
H150-9000N
400/440
50/60
3
10A/P
10
20
5900
30800
