Lacanche CLUNY INDUCTION - Opening and Closing the Hob

INSTALLER’S MANUAL
To remove top :
1- Loosened the 2 screws (see
A
/ figure
1
) through the ventilation strip.
2. Lift the hob (figure
2
).
3- Wedge the hop open (see.
B
/ figure
2
).
OPENING AND CLOSING THE HOB
A
1
2
B
1.Pull foward
2. Lift the table
Retting the cooking surface
When refitting the cooking surface, it is vital to tighten the fastening screws. Failure to do so can
cause distortion of the hob top.
It may be necessary to open the hob under the following circumstances :
- Making adjustments when changing gas type.
- Adjusting thermocouples.
- Resetting the safety thermostat.
Cluny induction - Ft 151a - GB - Rév 05 - Modifié le : 07/10/2013 9/31
