The use of any accessory or attachment or performance of any operation with this tool other than
those recommended in this instruction manual may present a risk personal injury.
SAW FEATURES
1. Main frame
2. Lower splash tray
3. Upper splash tray
4. Anti-splash guard
5. Motor/arm assembly
6. Blade guard
7. On/Off switch
8. Blade
9. Worktable
10. Miter guide
11. Water tray
12. Table extension
13. Drain plug (not shown)
14. Submersible pump (not shown)
Inset
15. Water hose
16. Bevel lock knob
17. Height Adjustment Knob
& Wing Locknut
18. Depth of cut lock knob
1
2
3
4
10
12
8
9
5
6
7
16
17
18
15
11
7
