Built-in web server for accessing device data and conguration Data logger with
graph representation and data export in text format Alarm management with list of
current events, list of stored events, e-mail or SMS sending Management of several
users with different access rights and alarm messages reception Simplied conguration
through templates of LAE controllers and automatic detection of the connected devices
Communication ability in absence of Internet line and SMS sending by connecting an
external analog or GSM/GPRS modem Ability to get access to data through Internet
portal 2 digital inputs that may be monitored and controlled as external alarm sources.
MAin feAtuReS
Ethernet port:: 10/100 Mbit/s, RJ45 connector
Serial port #1: RS-485, screw terminal
Serial port #2: RS-232 DSUB 9-pin connector
Power supply: 9÷24V AC/DC 2W
Operating temperature: -40÷65°C
Housing: DIN rail, 4 modules, 90x70x58mm
Certication: EN 61000-6-2:2005 and 61000-6-4:2001, UL 508
technicAl dAtA
