10
4 Connect the Suction Catheter Adapter to
the Patient Tube.
5 Connect the Angled Connector to the Patient
Tube.
6 Mount the yellow Vacuum Seal in the centre
hole of the Lid and push it into place.
7 Connect the Aerosol Filter (blue ring) to the
blue Vacuum Inlet on the LSU. (Color code:
Blue on Blue)
8 Insert the Canister in the canister holder and
slide it into the LSU.
9 Connect the yellow Angled Connector to the
yellow Vacuum Seal
10 Connect the Angled Connector on the Patient
tubing to the PATIENT Inlet on the canister Lid.
11 Perform the Device Test according to section 7.
12 Wind the Patient Tubing on the Patient
Tubing Holder.
13 Place the LSU on charge (see section 6.4)
