11. Specifications
11.1 Classification
Electrically powered medical suction equipment
for field and transport use, according to
ISO10079-1
High vacuum/high flow.
Not suitable for use in the presence of flammable
liquids or gases.
Internally powered/class ll equipment type BF,
according to IEC 60601-1
The degree of protection provided by the chassis
is according to IP34D:
• Protected against solid foreign objects of
2,5 mm Ø and greater
• Protected against splashing water
• Protected against access with a wire
11.2 General tolerance
Overall tolerance ±5%
11.3 Physical Characteristics
Size: 315 mm (12,4 in) x 330 mm (13 in) x 160
mm (6,3 in), (h x w x d)
Weight: 4kg (8,9 lbs) (including battery NiMH)
Canister Capacity: 1000 ml
Canister graduation
accuracy: ±5% of full scale
Patient Suction Tubing
(non-sterile) Cat.No 770410: 8 mm (0.315 in.)
inside diameter x 1.5 m (59 in.) length
11.4 Operation
Approx. free air flow at different settings:
mmHg 80 120 200 350 500+
l/min 12 16 20 23 >25
Approx. battery operation time (free air flow) at
different settings (±10%):
mmHg 80 120 200 350 500+
min 3h20 2h20 1h30 1h 45
Approx noise levels (free air flow) at different
settings:
mmHg 80 120 200 350 500+
dBA 48 48 51 53 56
Vacuum - Max.: > 500 mmHg (67 kPa).
Vacuum - Range: 80 - 500+ mmHg (11 - 67 kPa).
Vacuum Indicator accuracy: ±5% of full scale.
11.4.1 Operation with High Efficiency Filtration
Kit
The flow and operation time of the LSU will be
reduced when the Vacuum Connector Tubing is
replaced with a High Efficiency Filtration Kit.
The LSU with High Efficiency Filtration Kit
installed is in accordance with ISO 10079-1.
The filter has an efficiency of 99.97% down to a
particle size of 0.3 μm.
11.5 Power Requirements
Operating/charging AC:** 100-240 VAC +10%/-
15%, 50-60 Hz +/- 3 Hz (100-240 VAC),
Operating/charging DC:** 12-28 VDC +/-10%.
Battery: 12 VDC 2 Ah, NiMH, rechargeable, 12
VDC 2 Ah, Sealed Lead - Acid, rechargeable
Charging Time: 3 hours for approx. 80% battery
capacity, 24 hours for fully charged.
Fuses: The LSU has no fuses to be replaced by
the user (see section 9).
** The external AC power source must be able
to deliver a current of min. 1A and the external
DC power source min. 6A, if not the LSU may
switch to battery operation.
