LAGOON 400
ELECTRICITY
62
30A SHORE POWER 40A BREAKER
INVERTER 12V / 220V
Lay out of: Port aft cabin
1. Inverter 2000VA
2. 300A fuse
Earth-Lay out of:
Passageway - To port
Control
ELECTRONIC
Position of elements:
Lead lines
(Reference 1)
Pilot elements
(Reference 2)
Tiller
(Reference 3)
ELECTRICITY
