ELECTRICITY
75
7
ELECTRICITY
l
GENERATOR
The generator (optional extra) is located in the port locker of the
forward swim deck.
Its function is to re-supply the batteries via the chargers and supply
110 V - 220 V electricity on board.
OPERATION
After turning ON the cut outs located in the central locker of the forward
swim deck, the generator can be switched on either at the generator
itself or via the touchscreen on the chart table.
- Make sure that the seawater cooling valve (access under the floor of
the port passageway) and separator drain valve (access via the tech-
nical room in the port bow).
- Select the fuel tank using the pull handle located to starboard of the
aft port cabin berth.
For the use and maintenance of the generator, please refer to its ins-
truction guide.
n 7.4 110 V - 220 V circuit
l
SHORE POWER SOCKETS
Both shore supply sockets are located in the starboard transom.
They supply the 220 V circuit and the battery chargers, as well as the
air conditioning.
One socket only supplies power to the 110 V circuit, the battery char-
gers and air conditioning.
Before you plug in or unplug the boat / shore power supply cable, swit-
ch off the shut off device connected to the shore supply.
Connect the boat / shore power supply cable in the boat before connec-
ting it to the shore supply socket.
Unplug the boat / shore supply cable on shore first.
Close the protecting cover of the shore supply socket when you do not
use the plug.
The shore power plants are protected by circuit breakers located in the
starboard engine compartment (+ two automatic breakers located in
the starboard companionway).
WARNING
Before using the shore power socket, imperatively
check the shore power is 32 Ah.
DANGER
Never let the end of the boat / shore supply cable
hang in the water; the result may be an electric field
liable to hurt or kill the swimmers nearby.
