Please note: you can find the same locations
in the other accommodation version.
ENGINE LAYOUT
86
MOTORIZATION
1 - Fuel valve.
2 - Fuel tank.
3 - Fuel filter.
4 - Sea water filter.
5 - 12 V battery.
6 - Engine.
7 - Engine water inlet valve.
8 - Starboard engine cut-out.
9 - Fuel tank filler.
10 - Port engine + coupling cut-outs.
Each hull has the same components.
Nota: each valve in the boat is identified.
1
5
WATER FILTER
POWER SUPPLY SWITCH ENGINE WATER
INLET VALVE
STARBOARD ENGINE
CUT OUT
PORT ENGINE +
COUPLING CUT-OUTS
2
4
3
9
6
7
8
10
