1. Reference
CO2 Laser Machine © 2018 Laguna Tools 8/27/2018
1. ReferenceEN
Specification
Laser | TX
Laser | MX
Laser | EX
Shipping Dimensions
Overall Size
L51.8" W26" H17.7"
(L1300mm W660mm
H450mm)
Stand: +27" to Height
L53.5" W39.8" H42.1"
(L1360mm W1010mm
H1070mm)
L71.7" W51.6" H42.1"
(L1820 W1310
H1070mm)
1.1.3 Machine Type: CO2 Laser NOTE: W - width (front to back). L - length (left to right)
Laser Type
Sealed Water Cooled CO2 laser tube
Laser Power
50W
80W
120W
Work Envelope
(fit a work peice in)
L19.7" W11.8" H
(L500mm W300mm)
L35.4" W23.6" H
(L900mm W600mm)
L53.5" W37.6" H
(L1,360mm W955mm)
X-Axis Range (limit)
19.7" (500mm)
34" (865mm)
53.1" (1350mm)
Y-Axis Range (limit)
11" (280mm)
23.22" (590mm)
37.4" (950mm)
Z-Axis Range (limit)
6.3" (160mm)
12.6" (320mm)
8.66" (220mm)
Process Speed*
0-2125 in/min (0 -
54,000mm/min)
0-2350 in/min (0 - 60,000mm/min)
Resetting position
accuracy
±0.02" (0.05mm)
Controlling Software
Ruida
Design Software Integration
(not included)
CorelDraw, AutoCAD Photoshop
Graphic Format Supported
BMP, PLT, DST, DXF, and AI
Color Separation
Yes
Working Environment
33-112 Fahrenheit (1-45 Celsius)
(*) Optimal processing speed will vary between cutting or engraving, depth of cut, material characteristics, and working
environment. The metric shown is the maximum pace the drive system can produce.
1.1.4 Dimensions See Dimensions sections for Diagrams. NOTE: W - width (front to back). L - length (left to
right)
Overall Size
L51.8" W26" H17.7"
(L1300mm W660mm
H450mm)
Stand: +27" to Height
L53.5" W39.8" H42.1"
(L1360mm W1010mm
H1070mm)
L71.7" W51.6" H42.1"
(L1820 W1310
H1070mm)
Work Envelope
(fit a work peice in)
L19.7" W11.8" H
(L500mm W300mm)
L35.4" W23.6" H
(L900mm W600mm)
L53.5" W37.6" H
(L1,360mm W955mm)
X-Axis Range (limit)
19.7" (500 mm)
34" (865 mm)
53.1" (1350 mm)
Y-Axis Range (limit)
11" (280 mm)
23.22" (590 mm)
37.4" (950 mm)
Z-Axis Range (limit)
6.3" (160 mm)
12.6" (320 mm)
8.66" (220 mm)
Focal Lens Diameter
20mm
20mm
20mm
1.1.5 Fume Extraction
Dust Port Outer Diameter
3.95" (100mm)
2x 5.95 (150mm)
5.95 (150mm)
CFM Requirement
400CFM
400CFM Fume
600CFM Debris (lower)
600CFM
Specification
Laser | TX
Laser | MX
Laser | EX
1.1.6 Materials
Cabinet
Sheet Steal
Optical Lens
Zinc Selenide (ZnSe)
Linear Rails
Low Friction Stainless Steel
Laser Head Assembly
Aluminum
1.1.7 Features
Automatic Focusing
Precision Linear Guide Rail
Z Axis Control
Dust Debris Extraction
in addition to fume extraction
NO
NO
Beam Combiner Red Dot
Sight
NO
Head Assembly Red dot
sight
NO
U.S II-VI Optical Lenses
Honeycomb Table
Wifi Control
Integrated HEPA Filtration
NO
NO
Auxiliary Exhaust Fan
Auxiliary Chiller System
Auxiliary Air Pump
NO
1.1.8 Accessories & Options
Rotary 4th Axis
SKU: 3 Jaw Rotary
80mm Dia 480mm
Length
SKU: 3 Jaw Rotary 80mm Dia 480mm Length
SKU: 3 Jaw Rotary 80mm Dia 600mm Length
SKU: 3 Jaw Rotary 120mm Dia 600mm Length
Key: V - voltage. PH - phase. HZ - hertz. FLA - full load amperage. HP - horsepower. kW - kilo watt. AMP - amperage. L - length
(left to right). W - width (front to back). H - height (bottom to top). M - meter. Ft - foot. MM - millimeter. (") or IN - inch. MPA -
mega pascals. PSI - pounds per square inch. LB - Pound. Kg - Kilogram. CFM - cubic feet per minute.
Disclaimer: The information contained in this publication was correct at the time of print written on the front of this manual. In
the interest of continuous innovation, we reserve the right to change specifications, design or included equipment without
notice or obligation. No part of this publication may be reproduced, transmitted, or translated into any language in any form
by any means without our written permission. Errors and omissions may be current.
