09. Before securing the metal plate, thread the printer cables (USB and power)
through and line up with the two holes on the metal plate
08. Connect the cables from the floor stand to the kiosk cables. There is an ethernet,
USB cable and power cable to connect. The floor stand USB cable should connect
to the yellow USB cable on the kiosk. Also connect the USB cable supplied with the
badge printer to the the white USB cable on the kiosk.
18
