LamasaTech LD-AITemp-Device - Wall Mount Kiosk Setup (Zentron 15)

01. Mark out where the drill holes will
need to be, look at following diagram
for measurements
02. Drill into the wall using a 6mm drill
bit
03. Place the rawl plugs
into the drilled holes
32
Wall mount and kiosk set-up - Zentron 15
*Measurement is from centre to centre of circle
70mm
70mm
70mm
70mm
101mm
4mm
