lamber 050F - Connection Scheme

Dis.2
L
E
E
S
600 650
350
820
320
370
50
65
650
A
L
S
E
380
260
200
S
SCHEMA ALLACCIAMENTI
INSTALLATION
INSTALLATION
INSTALLATIONSBLATT
050F
E
L
S
Elettrovalvola carico - Electrovanne chargement
Water inlet - Wasseranschluß
Linea elettrica - Branchement eléctrique
Electric input - Einführungsrohr
Drain - Ablauf
3/4" G
32 mm - 1"1/4 G
Scarico acqua - Evacuation Eau
A
Altezza massima per scarico a muro - Hauteur maximale pour vidange à mur
Maximum height for drain to wall - Maximale Bodenhöhe für Wandwasserablauf
230 V1N 50Hz
35
