SCHEMA ALLACCIAMENTI
INSTALLATION
INSTALLATION
INSTALLATIONSBLATT
S400-ek/S460-ek/S480-ek
E
L
S
Entrata acqua - Chargement eau
Water inlet - Wasseranschluß
Linea elettrica - Branchement électrique
Electric input - Netzanschluß
Drain - Ablauf
3/4" G
32 mm - 1"1/4 G
Dis.2
Scarico acqua - Evacuation Eau
L
S
S
E
S
E
482
510
S400-ek=675
S460-ek=260
S400-ek=240
S400-ek=275
315
50
50
A
A
Altezza massima per scarico a muro - Hauteur maximale pour vidange à mur
Maximum height for drain to wall - Maximale Bodenhöhe für Wandwasserablauf
L
S
E
285
135
510
75
230 V 50Hz
35
S460-ek=695
S480-ek=740
S480-ek=300
S460-ek=295
S480-ek=325
