188
7 Operating Control and Displays
NOTICE
Only parameters at the current access level can be changed!
All parameters not at the current access level are greyed-out and cannot be changed.
A reset must be performed after changing some parameters. This is indicated with a system
message.
Accessing the ’AEC Parameter’ submenu
Fig. 7-66 CMS AEC parameters
Setting and changing values
1. Double-click to select the parameter value.
2. Confirm value with the ENTER key or select a different parameter.
NOTICE
Only parameters at the current access level can be changed!
All parameters not at the current access level are greyed-out and cannot be changed.
A reset must be performed after changing some parameters. This is indicated with a system
message.
1 The password can be entered here (padlock symbol)
