5 Operating Control and Displays
5.6.3 Other Displays
No connection between UI300 and BT300
Display shown e.g. when using LSB remote software and communication between BT300 and
UI300 is temporarily unavailable.
Termination
Fig. 5-46 No connection
1 UI300 User Interface pictogram
2 No connection symbol
3 BT300 burner control
Fig. 5-47 Termination
1 Communication error pictogram
connection unavailable
