Land Pride FD1548 - Wheel Bushing; Wheel Support Bushings; Bearing in Blade Spindle Hubs

16
Section 5 Maintenance and Lubrication
FD1548 & FD1560 3-Spindle Grooming Mower 310-155M
7/18/08
Land Pride
Table of Contents
Bearing in Blade Spindle Hubs
Type of Lubrication: Multipurpose Grease
Quantity = Until grease starts to purge from the top bearing. Top
bearing has a purge gap which allows grease to purge from it.
Wheel Support Bushings
Type of Lubrication: Multipurpose Grease
Quantity = Until grease starts to purge.
8
Wheel Bushing
Until grease starts to purge.
Type of Lubrication: Multipurpose grease
Quantity = Until grease starts to purge
15040
15040
Seasonally
25
16646
