Section 6 Specifications & Capacities
FD1548 & FD1560 3-Spindle Grooming Mower 310-155M
7/18/08
Land Pride
Table of Contents
Section 6 Specifications & Capacities
FD1548 & FD1560 3-Spindle Grooming Mower
l FD1548 FD1560
Cutting Width
48" 60"
Overall Width
59” 71”
Height
36" 36"
Length
44” 56”
Weight
400# 440#
Blades - 3
1/4” x 2 1/2” x 16 3/4”
Heat Treated
Alloy Steel
1/4” x 2 1/2” x 20 3/4”
Heat Treated
Alloy Steel
Blade Tip Speed
15,000 FPM 15,000 FPM
Cutting Height
1 1/2" - 4 1/2" {1/2" Increments}
Deck Material Thickness
10 Gauge
Blade Overlap
1 1/4"
1 1/2"
Blade Spindles
Greasable
Hitch
Cat. 1 Floating Clevis
Cat. 1 Floating Clevis
Gauge Wheels
Castered 2 3/4" x 8 1/4" Solid Tire
Caster Wheel Spindle
1" Diameter With Greasable Bushing
Drive Train
540 RPM PTO
Gearbox
1:2.83 Ratio
Beveled Gears
Cast Iron Housing
Spring loaded Single V-Belt
