Land Pride FSP300 - Lubrication Points

28
Section 5: Maintenance
FSP300, FSP500, FSP700 & FSP1000 Broadcast Spreaders 309-065M
Table of Contents
11/19/24
15356
15357
Driveline
Grease all knuckle points daily. This includes the zerks, and
tubes of the driveline shaft.
Lubrication Points
Gearbox
Type of Lubrication:
Use Lithium Base gun grease, Grade 2 rated for gearbox
application.
Quantity = 3 pumps every 25 hours.
NOTE: DO NOT OVERFILL, SEAL DAMAGE CAN
OCCUR. There is no purge hole in gearbox!
Gearbox can be checked for grease level by
removing grease zerk. Grease should be up to
bottom of zerk hole when full.
25
Hours
Seasonally
50
Hrs
Multi-purpose
spray lube
Multi-purpose
grease lube
Multi-purpose
oil lube
Intervals in hours at which
lubrication is required
Lubrication
Legend
