Section 6: Specifications & Capacities
FSP300, FSP500, FSP700 & FSP1000 Broadcast Spreaders 309-065M
Table of Contents
11/19/24
Section 6: Specifications & Capacities
FSP300, FSP500, FSP700 & FSP1000 Broadcast Spreaders
Specifications & Capacities
Model Numbers
FSP300 FSP500 FSP700 FSP1000
Capacity (maximum Cu.ft. & pounds) 4.8 cu. ft. (288 lbs)
[.14 m³ (130.6 kg)]
5.83 cu. ft. (350 lbs)
[.17 m (158.8 kg)]
9.18 cu. ft. (563 lbs)
[.26 m (255.4 kg)]
12.18 cu. ft. (673 lbs)
[.34 m³ (305.3 kg)]
Overall dimensions 35 1/2" x 37.5"
(.9 m x .95 m)
37" x 40" (0.94m x
1.02m)
44" x 46" (1.12m x
1.17m)
47" x 46" (1.19m x
1.17m)
Loading height less than 36"
(.91 m)
36" (0.91 m) 41" (1.04 m) 44.5" (1.13 m)
Weight 110 lbs (50 kg) 119 lbs (54 kg) 128 lbs (58 kg) 139 lbs (63 kg)
3-Point attachment Category 1 (Quick
Hitch Compatible)
Category 1 Category 1 Category 1
Net spreadable width
Granular
Crystalline
up to 54 ft (16 m)
27 ft (8 m)
23-54 ft (7-16 m)
12-27 ft (4-8 m)
23-54 ft (7-16 m)
12-27 ft (4-8 m)
23-54 ft (7-16 m)
12-27 ft (4-8 m)
Power take-off shaft type 1 3/8" 1 3/8" 1 3/8" 1 3/8"
Transmission ratio 1:11:11:11:1
Min. tractor horsepower 15 hp (11.2 kW) 15 hp (11.2 kW) 18 hp (13.4 kW) 20 hp (14.9 kW)
Range of
spreading
Possibility
lbs/acre
kgs/hectare
44 - 890
(49 - 998)
44 - 890
(49 - 998)
44 - 890
(49 - 998)
44 - 890
(49 - 998)
UP TO
APPROX 54'-0" (16.46m)
