Agitation Extension Kit (Accessory)
Refer to Figure 5-1:
Extended agitator paddles can be added to your existing
paddles in the main seedbox to help break-up bridging of
light fluffy seed across the seedbox discharge opening.
See your nearest Land Pride dealer to order the correct
kit for your seeder.
313-505A Agitator Extension Kit, 72" Box Width
Refer to Figure 5-2:
Install extended agitator paddles to existing paddles in
the main seedbox as follows:
1. Attach extension paddles (#2) to existing paddles as
shown with 1/4"-20 x 5/8" GR5 cap screws (#3) and
hex nylock nuts (#4).
2. Tighten all nylock nuts to the correct torque.
Slow Moving Vehicle Sign (Accessory)
Refer to Figure 5-3:
Land Pride offers as an accessory the SMV sign with
attached mounting blade (#1) should your tractor not be
equipped with a removable SMV sign or should your SMV
sign not fit Land Pride’s SMV mounting socket (#4). Also,
mounting components (#2, #3, & #4) can be purchased
from your nearest Land Pride dealer should you want to
mount this SMV sign on another piece of equipment.
Item Part No. Description
1 316-362S SMV Sign
2 802-092C RHSNB 5/16-18X3/4 GR5
3 803-177C NUT HEX FLG TP LK 5/16-18ZNYCR
4 890-401C SMV MOUNTING SOCKET
Agitator Extension Kit
Figure 5-1
Assembly of Agitator Extension Paddles
Figure 5-2
Slow Moving Vehicle Sign
Figure 5-3
