Arc Thermal Imaging Camera Installation Guide
Page 2
2.1 LED Status Indicators
The LEDs on the rear face of the Arc Thermal Imaging Camera are used to indicate
the status of the camera operation.
The table below gives an explanation of the LEDs.
LED Colour Meaning
LED1 Orange Camera Settling
Green On
Blink Off Ethernet Command Event
Blink Red Shutter Event
LED2 Off I/O Disabled
Flashing Orange Connecting to I/O
Flashing Green/Orange Connected to I/O
Green Logged in to I/O
Blink Off I/O Update Event
Blink Red I/O Watchdog Event
2 Specifications
Model Range ARC-8-FOV-500-Rate ARC-8-FOV-1000-Rate
Temperature Range
0 to 500°C
32 to 932°F
100 to 1000°C
212 to 1832°F
Spectral Response 8 - 14µm
Image resolution 384 x 288
Horizontal FOV 11°, 22°, 44° or 60°
Focus range 0.3m>innity (22°, 44°, 60°) / 0.5m>innity (11°)
Accuracy ±2% or ±2°C
Frame
Rate
LF 7.5 Hz (export licence-free)
HF 30 Hz
Physical & Environmental
Dimensions 85 x 85 x 276 mm / 3.5 x 3.5 x 11 in (including lens)
Weight 1.8 kg / 4 lb
Ambient Range -20 to 60°C / -4 to 140°F
Operating Humidity 5% to 95% (non-condensing)
Sealing IP65 / NEMA 4X
Power I/O and EMC
Power Supply 9 to 30 Vdc
EMC EN 61326
