ZG SERIES PRESSURE WASHER OPERATOR’S MANUAL
9
LANDA ZG • REV. 5/02
ZG3-20321 • ZG3-20326
EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 2-2006 Nipple, 3/8" x 3/8" NPT ST Fem.1
2 5-2100 Pump, Comet ADX3020G
(ZG3-20326) 1
5-2325 Pump, Gen. TH3020G
(ZG3-20321) 1
3 2-300816 Pump Protector, 3/8" PTP 1
4 5-0101 Engine, Honda 5 HP 1
5 10-02025A Label, “Hot/Caliente” with
Arrows Warning 1
6 10-02029 Label, Danger Cool Engine 1
7 4-12804015 Nozzle, SAQCMEG 1504, Yellow
(ZG3-20321) 1
4-12803515 Nozzle, SAQCMEG 1503.5,
Yellow (ZG3-20326) 1
8 2-0103 Grommet, Rubber
Nozzle Holder 2
9 4-16540 Nozzle, Compl. QCEM-6540
Brass 1
10 95-07101143 Handle, ZG Black 1
11 10-9906 Label, Instr./Warning 1
ITEM PART NO. DESCRIPTION QTY
12 10-2032000 Label, 3-2000 1
13 10-020ZG Label, ZG 1
14 90-2002 Nut, 3/8", ESNA, NC 4
15 90-4002 Washer, 3/8", SAE, Flat 6
16 90-1009 Bolt, 5/16" x 1-1/2", NC 4
17 90-4001 Washer, 5/16", Flat, SAE 8
18 95-0727006 Frame, Welded ZG 1
19 90-1017 Bolt, 3/8" x 1-1/4", NC HH 2
20 4-0305 Wheel & Tire, 8" x 1.75",
Semi-Pneumatic 2
21 90-2001 Nut, 5/16", ESNA, NC 4
22 2-01413 Bushing, 1/2" Axle,
1/2" x 5/8" x 3/4" w/Flange 2
23 2-01041 Pad, Soft Rubber 2
24 90-40125 Washer, 3/8" x 1", Steel 2
25 90-1016 Bolt, 3/8" x 1" NC HH 2
26 90-20039 Collar, 1/2" Bore Shaft, ZN 2
27 95-071010180 Axle, 14" ZG 1
