- 8 -
1) Take four provided 3mm X 30mm long
screw to tight up the EDF cover set.
Please be reminded to put some hot melt
on the both side of EDF in order to
strengthen the installation issue before
tight up the EDF cover.
10
1) Take some epoxy on the slot of horizontal
stabilizer then insert into the vertical
stabilizer slot.
11
1) Firstly, pass through the rudder control
push rod (with the pvc tube) from vertical
to horizontal stabilizer.
12
