Landoll 6230 - User Manual

96 pages

Save Page as PDF

To Next Page

To Next Page

Loading...

F-440-0110 01/2010

LANDOLL CORPORATION

1900 North Street

Marysville, Kansas 66508

(785) 562-5381

800-428-5655 ~ WWW.LANDOLL.COM

Model 6230

Disc

Operator’s Manual

Table of Contents

Questions and Answers

B
Brianna JohnstonJul 28, 2025
How to fix uneven depth on Landoll Farm Equipment?
- A
  Alyssa ClarkJul 28, 2025
  To fix uneven depth in your Landoll Farm Equipment, make sure the center frame is level from side to side. Also, level the wing frames to the center frame. Ensure the lift cylinders are in phase by fully extending them and holding the hydraulic lever until all cylinders are fully extended. Adjust the depth stop and raise the implement if the lift wheels aren't carrying enough weight. Fully extend the fold cylinders to allow the wings to flex. Check tire inflation and adjust the unit to be level from front to rear.
T
thomastoddAug 4, 2025
What to do if Landoll 6230 is not level, leaving ridge on outside of unit?
- K
  kingtonyAug 4, 2025
  If your Landoll Farm Equipment unit is not level and leaves a ridge on the outside, you should adjust the unit to be level, especially from front to rear, ensuring the front isn't running too deep. Adjust the side to side level, ensuring the wings are typically set even with or slightly higher than the center section. Reduce your operating speed if it's too fast, causing the front gang to move soil past the rear gang. Lower the implement hitch point if the hitch adjustment is too high. Properly reset the gauge wheels if they are too high, allowing the wings to go too deep.
M
Michael CarrilloAug 12, 2025
How to fix Landoll 6230 leaving center ridge?
- J
  Joseph RussellAug 12, 2025
  To correct a Landoll Farm Equipment unit that's not level and leaving a center ridge, adjust the leveler and lower the front gang. Raise the implement hitch point if the hitch adjustment is too low. Raise the gauge wheels if they are carrying too much weight.
R
Rodney SmallAug 20, 2025
How to fix Landoll 6230 Farm Equipment leaving center furrow?
- L
  Latoya ClayAug 20, 2025
  To fix a Landoll Farm Equipment unit that's not level and leaving a center furrow, adjust the leveler and raise the front gang. Lower the implement hitch point if the hitch adjustment is too high.

Summary

Chapter 2 Standard Specifications

General Torque Specifications

Provides torque specifications for general purpose applications and fasteners.

METRIC

Details metric thread torque specifications for fasteners.

Hydraulic Fitting Torque Specifications

Lists torque specifications for various hydraulic fitting brands and types.

Chapter 3 Assembly Instructions

6230 Disc Frame and Hitch Assembly

Step-by-step instructions for attaching the hitch weldment to the center frame assembly.

Leveler Assembly

Guide for assembling the disc leveler linkage and related parts.

Manual Leveler

Instructions for assembling the manual disc leveling mechanism.

Hydraulic Leveler (Option)

Detailed procedure for installing the hydraulic disc leveling system.

Hydraulic Depth Stop Tube Assembly

Procedure for installing the hydraulic depth stop tube and related components.

Electronic Depth Stop (Option)

Procedure for installing and connecting the electronic depth control system.

Fold Cylinder Mount

Steps for mounting the fold cylinders on various disc models.

Disc Gangs

Details on attaching disc gang assemblies to the center and wing frames.

Wing Frames

Instructions for attaching wing frames, tires, and gauge wheels.

Light Installation

Steps for mounting lights, reflectors, and the SMV emblem.

Rear Tow Hitch Installation

Steps for installing the optional rear tow hitch assembly.

Harrow Installation

Procedure for installing the optional coil tine harrow attachment.

Rear Jack Installation

Instructions for installing the optional rear jack assembly for stability.

Final Assembly

Final steps including hydraulic system charging, connections, and inspections.

Chapter 4 Operation and Maintenance

Tractor and Disc Preparation

Pre-operation checks and preparation for the tractor and disc.

Attaching and Hydraulic Systems

Procedures for attaching the disc and operating lift/fold hydraulic systems.

Leveling Procedures

Instructions for adjusting side-to-side and front-to-rear leveling.

Hitch and Scraper Adjustment

Guidance on adjusting the hitch and disc scrapers for optimal performance.

Disc Blade and Wheel Maintenance

Information on disc blade care, front gauge wheels, and wheel bearing maintenance.

Transport and Lubrication

Guidelines for safe transport and essential lubrication points and schedule.

Storage Procedures

Recommendations for proper off-season storage to prolong equipment life.

Chapter 5 Troubleshooting Guide

Landoll 6230 Specifications

General

Type	Disc Harrow
Category	Farm Equipment
Tire Size	11L-15
Axles	2
Disc Blade Size	24 in
