MAINTENANCE AND LUBRICATION
TABLE OF CONTENTS
Figure 4-1: Lubrication Points (1 of 2)
WINCH GEAR
CASE (#2,3,4,5)
WINCH CABLES
(#7)
KINGPIN
PLATE (#6)
HYDRAULIC RESER VOIR
(ENGINE PACKAGE)(#1)
HUB OIL (#8)
LANDING GEAR (#6)
ENGINE
CRANKCASE (#9)
TAIL ROLLERS (#6)
CAMSHAFT BUSHINGS
SLACK ADJUSTERS (6)
CENTRALIZED
GREASE SYSTEM
