Landoll 930E - Page 54

3-14 F-934-0418
MAINTENANCE AND LUBRICATION
TABLE OF CONTENTS
Figure 4-8: Checking Axle for Bend
Figure 4-9: Examples of Camber
GAP INDICATES
BEND
SET POSTION
(TOP OR BACK)
AXLE
CHECK POSITION
(BOTTOM OR FRONT)
3-POINT AXLE
GAUGE
POSITIVE CAMBER
ROAD
NO CAMBER
ROAD
NEGATIVE CAMBER
ROAD
SQUARE
SQUARE
SQUARE
