Landoll 930E - Standard Specifications; Specific Bolt Torques

2-1
TABLE OF CONTENTS
Chapter 2
Standard Specifications
MODEL 930E/950E
CAPACITY
MODEL 930E TANDEM AXLE
DECK RATING
HYDRAULIC TAIL RATING
70,000 LB. Distributed
50,000 LB. Distributed
24,000 LB. Distributed
MODEL 950E TRIPLE AXLE
DECK RATING
HYDRAULIC TAIL RATING
100,000 LB. Distributed
70,000 LB. Distributed
24,000 LB. Distributed
GOOSENECK
NON-TILTING
KING PIN SETTING
18”
UNDERCARRIAGE TRAVEL
60”
ELECTRICAL HOOKUP
7-Way Connector
AIR HOOKUP
Color Coded Gland Hands
HYDRAULIC TAIL
HYDRAULIC TAIL LOAD ANGLE - 12' TAIL
15°
HYDRAULIC TAIL LOAD ANGLE - 14' TAIL
13°
HYDRAULIC TAIL LOAD ANGLE - 15' TAIL
12°
DECK HEIGHT
38”
HYDRAULIC HOOKUP
QUICK COUPLERS
Flat Face, 3/4” Body Size
MAXIMUM OPERATING PRESSURE
2500 PSI
OPERATING FLOW
20 GPM Recommended; 50 GPM Max
(Flow control limits functions to 20 GPM)
SPECIFIC BOLT TORQUES
AIR RIDE SUSPENSION
EQUALIZER BEAM PIVOT AND ADAPTER BOLTS-
DESIGNATED W/ NEWAY ON BOLTHEAD
800 FT. LBS.
