Laney
CONCEPT MONITORS
10
CXM UNPOWERED MONITOR RANGE
Speaker Nom Impedance: 8 Ohms
Speaker Size: 10" + Piezo Tweeter
Speaker Rating: 125W RMS - 500W Peak
Frequency Reponse: 78hz to 20khz
Sensitivity: 97 dB/W@1M
Weight: 11.5Kg
Size (H*W*D): 274*468*347
Speaker Nom Impedance: 8 Ohms
Speaker Size: 12" + Piezo Tweeter
Speaker Rating: 180W RMS - 720W Peak
Frequency Reponse: 65hz to 18khz
Sensitivity: 98 dB/W@1M
Weight: 16Kg
Size (H*W*D): 330*591*437
Speaker Nom Impedance: 8 Ohms
Speaker Size: 15" + Piezo Tweeter
Speaker Rating: 250W RMS - 1000 Peak
Frequency Reponse: 60hz to 18khz
Sensitivity: 97 dB/W@1M
Weight: 21.5Kg
Size (H*W*D): 343*667*462
The CXM range of unpowered monitors are designed to compliment the CXP powered monitors, each of which is capable of
powering one unpowered monitor from its external speaker socket.
Each CXM monitor is supplied with two jack sockets on the rear panel, either can be used as an input or link out.
Other power amplifiers can be connected and depending on the specification of the power amplifier, it may be possible to link
together a number of unpowered monitors to achieve the desired monitor spread.
