Laney LFR-112 User Manual

9
USER MANUALLRF-112
www.laney.co.uk
LFR-112 GuitarAmplifier
Producttype
FullRangeFlatResponsePoweredLoudspeaker
Systemtype Active-2way
OperatingVoltageRange: ~100V/~120V/~220V/~230V/~240V50-60Hz-Switchable
Powerconsumption:
100W
PowerOutput(RMS): 200W
PowerOutputPeak: 400W
Unitdimensions:(mm)(HxWxD): 420x575x355
Unitweight(Kg): 19.5
Cartondimensions(mm)(HxWxD):
496x650x430
Weight(Kg):
21.5
Construction: Lightweight,plywoodconstruction
Blackvinylfinish
Ruggedbarhandles
Tiltmechanism
Drivers: 12"driverLF-436EH
1"LavoceDF10CompressionDriver
FrequencyResponse: 47Hz-20KHz
MAXSPL: 129dB

Laney LFR-112 Specifications

General

Power	200W
Speaker Size	12"
Outputs	XLR
HF Driver	1"
EQ	2-band EQ
Frequency Response	20kHz
Amplifier Type	FRFR
