Model No: FCOF & FCOFL Door Assembly
Commercial, Marine & Submarine Full Size Economy Convection Oven
PARTS LIST December 11, 2008, Rev B
Some items are included for illustrative purposes only and in certain instances may not be available.
Description
Part
Number
Key
Number
1 PS-50301-50-1 1 DOOR STOP ASSY L/H FCOFAT480SUB; FCOF 208M, 240M, 440G,AND
440M; FCOFL 208M, 240M, 440G, 440M, 480G,
AND 480M
2 Q9-F6-144-6 1 INSIDE DOOR PANEL S\S SUB FCOFAT480SUB; FCOF 480G; FLAT 480G,
FCOFLSL480VM
Q9-F6-144 1 INSIDE DOOR PANEL A/L FCOF 208M, 208V, 240M, 240V, 440M,480M, 480V;
FCOFL 208, 240, 480, 208M, 240M, 440G, 440M,
480M
3 2C-20602-04 2 TINNERMAN SPD NUT 1/8 DIA ALL MODELS
4 2H-F6-144-1 1 DOOR INSULATION ALL MODELS
5 Q9-F6-146 2 STIFFENER - DOOR HANDLE ALL MODELS
6 2C-20115-04 AR SCRW S/S 6-32X3/8 S/T P/H FCOFAT480SUB; FCOF 480G; FLAT 480G
2C-20103-06 AR SCRW SM PLT 6 X 3/8 PHL FCOF 208M, 208V, 240M, 240V, 440M,480M, 480V;
FCOFL 208, 240, 480, 208M, 240M, 440G, 440M,
480M
7 2R-50800-12 1 DOOR T HANDLE 11 1/2 LNG ALL MODELS
8 2C-20109-13 AR SCRW MS SS 10-32 X .5 PH ALL MODELS
9 2F-70601-06 AR HINGE PIN, HALF HINGE ALL MODELS
10 2C-20202-17 AR WSHR LOCK FOR 70601-27/28 ALL MODELS
11 2F-70601-05 AR PLATE & BUSH HINGE HALF ALL MODELS
12 2M-60301-43 1 DIE CAST PLT LANG SATIN ALL MODELS
13 Q9-F6-145 1 OUTSIDE DOOR PANEL ALL MODELS
NI Q9-F6-423-2 1 ASSEMBLY DOOR SUB-MARINE FCOF-AT-480G, FCOFAT480SUB, FCOFATSL480M,
FCOFL-AT440G, FCOFLSL208VM, FCOFLSL240VM,
FCOFLSL440VM, FCOFLSL480VM
NI Q9-F6-423 1 ASSEMBLY DOOR FCOF-AT-208V/M, FCOF-AT-240V/M, FCOF-AT-440M,
FCOF-AT-480V/M, FCOFL-AT-208, FCOFL-AT-240,
FCOFL-AT-480, FCOFL-AT208M, FCOF-AT240M,
FCOFL-AT440M, FCOFL-AT480M
Qty
Per
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 1
INCLUDE MODEL AND SERIAL NUMBER OF 1
