Model No: FCOF & FCOFL Can Assembly
Commercial, Marine & Submarine Full Size Economy Convection Oven
PARTS LIST April 5, 2010, Rev B
Some items are included for illustrative purposes only and in certain instances may not be available.
Description
Part
Number
Key
Number
1 Q9-F6-102-5 1 SPOT CAN TOP SUB FCOFAT480SUB
2 Q9-F6-102-7 1 SPOT CAN REAR SUB FCOFAT480SUB
3 Q9-F6-113-1 1 VENT PIPE ASSY SUB FCOFAT480SUB
Q9-F6-113 1 VENT PIPE ASSEMBLY FCOF 208M, 208V, 240M, 240V, 440G,440M,480M,
480V; FCOFL 208, 240, 480, 208M, 240M, 440G,
440M, 480G, 480M
4 2N-11090-09 1 ELMNT F6OVEN 208V 6KW FCOF 208M, 208V; FCOFL 208, 208M
2N-11090-10 1 ELMNT F6OVEN 240V 6KW FCOF 240M, 240V; FCOFL 240, 240M
2N-11090-11 1 ELMNT F6OVEN 480V 6KW FCOFAT480SUB; FCOF 440G, 440M, 480M, 480V,
480G; FCOFL 480, 440G, 440M, 480G, 480M
2N-11090-28 1 ELEMT F6OVEN 380V 6KW FCOFK-AT380M
5 Q9-F6-104-5 1 SPOT R/H CAN SIDE SUB FCOFAT480SUB
6 Q9-F6-159-2 1 CAN SIDE INSULATION SUB FCOFAT480SUB
2H-F6-159-1 1 INSULATION CAN SIDE UPPER FCOF 208M, 208V, 240M, 240V, 440G,440M,480M,
480V; FCOFL 208, 240, 480, 208M, 240M, 440G,
440M, 480G, 480M
7 Q9-F6-252-1 1 R/H SIDE REAR INSULATION FCOFAT480SUB
2H-F6-252 1 INSULATION-SIDE R/H REAR FCOF 208M, 208V, 240M, 240V, 440G,440M,480M,
480V; FCOFL 208, 240, 480, 208M, 240M, 440G,
440M, 480G, 480M
8 Q9-F6-188 1 MOTOR MNT ASY NO MTR SS FCOFAT480SUB
Q9-F6-189 1 MOTOR MOUNT ASSEMBLY NO FCOF 208M, 208V, 240M, 240V, 440G,440M,480M,
480V; FCOFL 208, 240, 480, 208M, 240M, 440G,
440M, 480G, 480M
9 Q9-F6-159-2 1 CAN SIDE INSULATION SUB FCOFAT480SUB
2H-F6-159 1 INSULATION CAN SIDE LOWER FCOF 208M, 208V, 240M, 240V, 440G,440M,480M,
480V; FCOFL 208, 240, 480, 208M, 240M, 440G,
440M, 480G, 480M
10 Q9-F6-251-1 1 R/H SIDE FRONT INSULATION FCOFAT480SUB
2H-F6-251 1 INSULATION-SIDE R/H FRONT FCOF 208M, 208V, 240M, 240V, 440G,440M,480M,
480V; FCOFL 208, 240, 480, 208M, 240M, 440G,
440M, 480G, 480M
11 Q9-F6-403 1 STAT HOLDER SPOTWELD ALL MODELS
12 Q9-F6-102-6 1 SPOT CAN BOTTOM SUB FCOFAT480SUB
13 2R-70602-03 1 CATCH DOOR MAGNET 3 PC ALL MODELS
14 2H-F6-158 1 CAN SIDE INSULATION ALL MODELS
15 Q9-F6-104-7 1 SPOT L/H CAN SIDE SUB FCOFAT480SUB
16 Q9-F6-405 1 BAFFLE SPOTWELD A/L FCOF-AT-208V/M, FCOF-AT-240V/M, FCOF-AT-440M,
FCOF-AT-480V/M, FCOFL-AT-208, FCOFL-AT-240,
FCOFL-AT-480, FCOFL-AT208M, FCOF-AT240M,
FCOFL-AT440M, FCOFL-AT480M
Q9-F6-405-1 1 BAFFLE SPOTWELD S/S FCOF-AT-480G, FCOFAT480SUB, FCOFATSL480M,
FCOFL-AT440G, FCOFLSL208VM, FCOFLSL240VM,
FCOFLSL440VM, FCOFLSL480VM
Qty
Per
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 1
INCLUDE MODEL AND SERIAL NUMBER OF 1
