Model No: FCOF & FCOFL Controls Assembly
Commercial, Marine & Submarine Full Size Economy Convection Oven
PARTS LIST October 4, 2012, Rev B
Some items are included for illustrative purposes only and in certain instances may not be available.
Description
Part
Number
Key
Number
1 2E-30701-03 1 CONTC2POL35A208-240V50/60 ALL MODELS
2 Q9-F6-138 1 CONTROL SLIDE SPOTWELD ALL MODELS
3 2J-30801-01 1 TIMER MECHANICAL LONG ALL MODELS
4 2E-30303-06 1 SWT TOG ON-ON DPDT BLK ALL MODELS
5 Q9-70701-09 1 KNOB MANUAL TIMER, BLACK
Q9-70701-09-2 1 KNOB MANUAL TIMER, RED
6 2R-70701-25 1 KNOB DAMPER BLACK PLAIN ALL MODELS
7 Y9-70701-19 1 KNOB 450o D, BLACK ALL MODELS
Y9-70701-19-2 1 KNOB 450o D, RED
8 2E-30901-02 2 FUS HLDR FOR 15AMP FUSE ALL MODELS
9 2J-31601-01 2 PILOT LT 250V 6LEAD BLK ALL MODELS
10 2T-30402-27 1 STAT ADJ 450 DEG 48 PILOT ALL MODELS
11 Q9-F6-165 1 MARINE CIRCUIT BREAKER FCOFAT480 SUB, FCOF 440G & 480G, FCOFL 440G
& 480G
12 2E-31800-07 1 CB 2/10 AMP 2 POLE FCOFAT480 SUB, FCOF 440G & 480G, FCOFL 440G
& 480G
12 2E-31800-01 2 CB 250V50A 1 POLE CRLNGSW FCOFATSL208M
13 2E-31400-04 1 XFRMR 480/240VAC 100VA FCOFAT480SUB; FCOF 440M, 440G, 480V, 480M,
480G; FCOFL 440M, 440G, 480, 480M, 480G
14 2E-31800-04 1 CB 480V 50A 3 POLE FCOFAT480SUB; FCOF 440M, 440G, 480V, 480M,
480G; FCOFL 440M, 440G, 480, 480M, 480G
15 2E-30700-03 1 CONTC 3POLE 40A208-240VAC FCOFAT480SUB; FCOF 440M, 440G, 480V, 480M,
480G; FCOFL 440M, 440G, 480, 480M, 480G
Qty
Per
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 1
INCLUDE MODEL AND SERIAL NUMBER OF 1
