Model No: FCOF & FCOFL Motor Fan Assembly
Commercial, Marine & Submarine Full Size Economy Convection Oven
PARTS LIST April 5, 2010, Rev B
Some items are included for illustrative purposes only and in certain instances may not be available.
Description
Part
Number
Key
Number
1 2C-20104-18 4 SCRW HXHDCP 5/16-18X1-1/4 ALL MODELS
2 2C-20201-09 AR WSHR PLT 5/16 FLAT SAE ALL MODELS
3 2A-20503-01 4 5/16IDX27/640DX5/16LG STL ALL MODELS
4 2I-70801-06 4 RUBBER GROMMET 7/16 I.D. ALL MODELS
5 2U-30200-03 1 MTR 1/3HP 480V 3PH 60HZ FCOFAT480SUB; FCOF 440G, 440M, 480M, 480V;
FCOFL 480, 440G, 440M, 480G, 480M
2U-30200-60 1 MTR 1/3HP 380V 1PH 50HZ 2SP FCOFL-AT380M
5 2U-30200-12 1 MTR 1/3HP 115/208-240 1PH FCOF 208M, 208V, 240V, 240M; FCOFL 208, 208M,
240, 240M
6 Q9-F6-180 1 MOTOR MOUNT WELDMENT ALL MODELS
7 2H-F6-184 1 MOTOR INSULATION ALL MODELS
8 Q9-F6-186 1 MOTOR INSULATION RETAINER ALL MODELS
9 2C-20301-13 AR NUT HEX 1/4-20 PLTD ALL MODELS
10 2C-20301-06 4 NUT HEX 5/16-18 PLTD ALL MODELS
11 2C-20202-08 4 WSHR PLT 5/16 LOCK SPLIT ALL MODELS
12 2C-20306-02 4 AVK CAD 1/4-20 1ST GRP ALL MODELS
13 Q9-F6-185 4 BLOWER SPACER ALL MODELS
14 2C-20203-07 4 WASHER S/S 1/4 SAE FLAT FCOFAT480SUB; FCOF 440G, 480G; FCOFL 440G,
480G
14 2C-20201-07 4 WSHR FLT 1/4 SAE PLTD FCOF 208M, 208V, 240M, 240V, 440M,480M, 480V;
FCOFL 208, 240, 480, 208M, 240M, 440M, 480M
15 2C-20104-14 4 SCRW HXHD TAPBOLT ALL MODELS
16 2C-20103-06 4 SCRW SM PLT 6 X 3/8 PHL ALL MODELS
17 Q9-F6-406 1 WELD ORIFICE RING ALL MODELS
18 Q9-F6-187-1 1 BAFFLE MOUNTING PLATE SUB FCOFAT480SUB
Q9-F6-181 1 MOTOR MOUNT PLATE FCOF 208M, 208V, 240M, 240V, 440M, 440G, 480M,
480V, 480G; FCOFL 208, 240, 480, 208M, 240M,
440G, 440M, 480M, 480G
19 2U-71500-03 1 BLOWER WHEEL F-6 ALL MODELS
Qty
Per
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 1
INCLUDE MODEL AND SERIAL NUMBER OF 1
