10
Board Layout
Chapter 3
Embedded and Industrial Computing
Chapter 3:
Board Layout
External Connectors
The following picture highlights the location of system
input/output connectors. Refer to the table 3.1 Connector
List for more details.
CN13/CN14
CN3/CN4
J1
CN5
CON15
CN19
CN6
CN1
CON16
SW9
CN12
USB1/USB2
LED1
