Lanner LEC-7920 - Internal Connectors and Jumpers (backside)

12
Board Layout
Chapter 3
Embedded and Industrial Computing
Internal Connectors and Jumpers
(backside)
The following picture highlights the location of internal
connectors and jumpers on the backside of the board.
Refer to the table 3.1 Connector List for more details.
J11
J6
J7
J8
