Lantronix SGX 5150 Command Reference

5: Commands and Levels
SGX™ 5150 IoT Device Gateway Command Reference 75
power management ena-
ble
Enables power management.
security
Switch to security level
show
Displays the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
tx power maximum
<dBm>
Sets the TX power maximum in dBm. <dBm> = measure of power in decibels with respect
to one milliwatt.
write
Stores the current configuration in permanent memory.
applications (config-applications) level commands
clrscrn
Clears the screen.
exit
Returns to the config level.
no reserved ports
Restores the default reserved ports.
no reserved start port
Clears the reserved start port.
python <instance>
Enters the next lower level. Specify the instance for the next lower level.
python install <zip|tar.gz
file>
Install a python package <zip | tar.gz file> = path of package to install.
python kill <pid>
Kill a python script <pid> = PID of running script or 'all' for all scripts.
python remove all
Uninstall python package and all installed packages.
python run <instance>
Runs a python script <instance> = index of the script to be executed.
python show installed
Show installed python packages.
python show status
Show running python scripts.
python uninstall
<zip|tar.gz file|File>
Uninstall a python package <zip | tar.gz file> = path of package to uninstall. <File> = file to
uninstall (from list of installed packages).
reserved ports <number>
Sets the number of reserved ports.
reserved start port
<number>
Sets the reserved start port. <number> = start port number.
show
Displays the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
write
Stores the current configuration in permanent memory.
arp (config-arp) level commands
add <IP address> <MAC
address> <Interface
name>
Adds an entry to the ARP table, mapping an IP address to a MAC address. <ip address> =
IP address to be mapped. <mac address> = MAC address in colon-separated form. <inter-
face name> = Interface name
clrscrn
Clears the screen.
exit
Exits to the configuration level.
remove all
Removes all entries from the ARP cache.
remove ip <IP address>
<Interface name>
Removes an entry from the ARP cache. <ip address> = address of the entry being re-
moved. <interface name> = Interface name
show cache
Displays the ARP cache table.
show history
Displays the last 20 commands entered during the current CLI session.
write
Stores the current configuration in permanent memory.
bluetooth (config-bluetooth) level commands
clrscrn
Clears the screen.
exit
Returns to the config level.
show
Displays the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
show statistics
Displays the Bluetooth statistics.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
