Lantronix SGX 5150 Command Reference

5: Commands and Levels
SGX™ 5150 IoT Device Gateway Command Reference 76
state disable
Disables Bluetooth.
state enable
Enables Bluetooth.
write
Stores the current configuration in permanent memory.
Bluetooth serial 1 (bluetooth-line:1) level commands
auto show statistics
Continuously displays line statistics.
bluetooth serial <line>
Enters the bluetooth serial level. <line> = number of the line (bluetooth serial port) to be
configured.
clear line counters
Sets the serial counters to zero.
clrscrn
Clears the screen.
command mode always
Sets the current line to always be in command mode.
command mode echo
serial string disable
Disables user-defined serial boot string to be echoed in the CLI.
command mode echo
serial string enable
Enables user-defined serial boot string to be echoed in the CLI.
command mode serial
string
Enables user to enter a custom string at boot time to enter command mode.
command mode serial
string <string>
Sets a string that can be entered at boot time to enter command mode. <string> = text with
possible binary characters. Within [] use binary decimal up to 255 or hex up to 0xFF. Within
{} specify decimal milliseconds time delay.
command mode signon
message <string>
Sets a sign-on message that is sent from the serial port when the device boots and when
the line is in command mode. <string> = text with possible binary characters. Within [] use
binary decimal up to 255 or hex up to 0xFF.
command mode wait
time <milliseconds>
Sets boot-up wait time for command mode serial string. <milliseconds> = wait time.
default line mode
Restores the default line mode.
default threshold
Restores the factory default threshold.
exit
Exits to the enable level
gap timer <milliseconds>
Sets the gap timer in milliseconds. If some data has been received, it will be forwarded
after this time since the last character.
interface bluetooth-
rfcomm
Sets the line interface to bluetooth-rfcomm.
kill session
Kills command mode session on the Line
line <line>
Enters the line level. <line> = number of the line (serial port) to be configured.
line mode serial device
Sets the line to serial device mode.
name <text>
Sets the name for this line.
no clear line counters
Restores the serial counters to the aggregate values.
no command mode
Disables command mode for the current line.
no command mode si-
gnon message
Clears the signon message displayed at boot time and when entering command mode.
no gap timer
Removes the gap timer, so forwarding depends on the line speed.
no name
Removes the name of this line.
protocol none
Uses no protocol on the line.
protocol tunnel
Applies tunnel protocol on the line.
show
Displays the current status.
show bluetooth line
Displays the current configuration.
show command mode
Shows the command mode settings for the current line.
show history
Displays the last 20 commands entered during the current CLI session.
show statistics
Shows the line statistics.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
