Lanzar SDN71BT - Unit Control Locations

1.6 The Locations and Names of Controls on or in the unit
1 2
3 4 5
6
7
8
The Diagram of the Face of the Front Panel
11
The Diagram of the Face of the Unit After Sliding down the Front Panel
SD/MMC
MUTEMIC
ANGMODE
_
+
EJECT
RESET
AUX IN
9
10
12
1. POWER/MUTE button
2. ANG button
3. MODE button
4. + and - buttons
5. IR remote sensor
6. RESET button
7. USB jack
8. AUX IN jack
9. EJECT button
10. Disc slot
11. SD/MMC Card slot
12. Microphone
