Lanzar STS65BT - Electrical Connection; Wiring Diagram and Connections

10
ELECTRICAL CONNECTION
NOTE : WHEN CONNECT / DISCONNECT THE GPS BOX WITH THE
MAIN UNIT, YOU SHOULD TURN THE POWER OFF.
+
-
-
+
FRONT RCA
CABLE(BROWN)
PINK
(GREY)
(BLACK)
(YELLOW)
(GREEN)
RGB Input
FUSE
SUBWOOFER (GREEN)
COAXIAL (ORANGE)
L IN (WHITE)
R IN (RED)
VIDEO IN (YELLOW)
R OUT (RED)
L OUT (WHITE)
VIDEO OUT (YELLOW)
(RED)Rch
(WHITE)Lch
(RED)Rch
(WHITE)Lch
REAR RCA
CABLE(GREY)
(FOR RCA LINE OUT
VERSION ONLY)
FRONT Lch
SPEAKER
REAR Lch
SPEAKER
WHITE
WHITE/BLACK
GREEN
GREEN/BLACK
BLUE
RED
1A
YELLOW
BLACK
GREY
GREY/BLACK
VIOLET
VIOLET/BLACK
FRONT Rch
SPEAKER
REAR Rch
SPEAKER
NEXT TO IT (PARKING SWITCH)
POWER ANTENNA
IGNITION SWITCH (ACC+)
MEMORY BACK UP (B+)
GROUND (B-)
