Lanzar VIBE218 - Page 5

Viberant Owner’s Manual4-
Specifications
MODEL Vibe218 Vibe 228 Vibe 238 Vibe248
RMS at 4 Ohms 2 x 100W 2 x 150W 2 x 200W 2 x 300W
MAX at 4 Ohms 2 x 200W 2 x 300W 2 x 400W 2 x 600W
At 4 Ohms Bridged 1 x 400W 1 x 600W 1 x 800W 1 x 1200W
RMS at 2 Ohms 2 x 150W 2 x 200W 2 x 300W 2 x 500W
Min. Speaker Impedance 2 Ohm 2 Ohm 2 Ohm 2 Ohm
T.H.D. 0.04% 0.04% 0.04% 0.04%
Frequency Response 15Hz-35KHz, -1dB 15Hz-35KHz, -1dB 15Hz-35KHz, -1dB 15Hz-35KHz, -1dB
Input Sensitivity 250mV-5000mV 250mV-5000mV 250mV-5000mV 250mV-5000mV
Input Impedance 22 KOhm 22 KOhm 22 Kohm 22 KOhm
S/N Ratio >90dB >90dB >90dB >90dB
Channel Separation >65dB >65dB >65dB >65dB
Crossover Filters
Low Pass 35Hz-400Hz 35Hz-400Hz 35Hz-400Hz 35Hz-400Hz
High Pass 80Hz-2.50KHz 80Hz-2.50KHz 80Hz-2.50KHz 80Hz-2.50KHz
Bass Boost +18dB +18dB +18dB +18dB
Dimensions (WxHxL) 11.5"x2.3"x8" 11.5"x2.3"x10" 11.5"x2.3"x12" 11.5"x2.3"x15"
Fuse(s) 15A 15A 20A 15Ax2
2 channel
amplifier
2 channel
amplifier
2 channel
amplifier
2 channel
amplifier
